BJ-03MAX Cable Stripping Machine

Product Description

Operation Video

Specification

* Model: BJ-03MAX  FOUR DRIVERS
* Power: AC220/ 50HZ 110V/60HZ
* Power: Rated 450W
* Display: Full English LCD Display
* Cutting length: 1-150000mm
* Stripping length: End of a thread 0-150 line tail 0-60
* Motor Step Angle Accuracy: 3-phase 6 shot 1.5/3
* Cutting Tolerance: ±(0.002xL) mm or less
* Cut the middle of stripping: 13
* Wire size: AWG5-AWG30#
* Core cross-section cut-line: 0.2– 25mm²
* Conduit diameter: Φ13
* Appropriate wire stripping: PVC, Teflon, glass and wire
* Blade Material: Hard tungsten steel
* Stripper speed (Article / h): L=100mm, 2000~5000pcs/hour
* Drive Mode: Eight drives
* Package Size: 420*390*280mm

Payment & Delivery

* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.

We Provide

* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.

Service

* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
